Product Features：
Tension measuring 128 * 64 LCD display, late-model design, comfor table handfeel , easy operation, measure the value of direct display tension, maximum, minimum, and can store records of measurements to determine the quality control of the actual tension values. It can be widely used in wire, st r ip processing time of tension measurements (such as: yarn, steel wire, copper wire, copper strip, tape, film, fiber-optic cable, carbon fiber lines, etc.).
|
Model |
YB101 |
YB501 |
YB102 |
YB502 |
YB103 |
|
Measurement Range |
0.1-100gf |
0.5-500gf |
1-1000gf |
0.01-5kgf |
0.1-10kgf |
|
Resolution |
0.1-1g |
0.5-1g |
1-10g |
0.01（kg or N） |
0.01（kg or N） |
|
Unit |
g、cN |
g、cN |
g、kg、N、lb |
kg、N、lb |
kg、N、lb |
|
Steel Wire（diameter mm） |
小于0.06 |
0.01-0.15 |
0.05-0.25 |
0.2-0.6 |
0.4-0.8 |
|
Brass Wires（diameter mm） |
小于0.1 |
0.05-0.25 |
0.1-0.4 |
0.3-1.0 |
0.5-1.2 |
|
Yarn、String（diameter mm） |
小于0.1 |
0.05-0.25 |
0.1-0.4 |
0.3-1.2 |
0.5-1.4 |
|
Precision |
±1%R.C. |
±2%R.C. | |||
|
Size （mm） |
（W）59×（D）78×（L）183 |
（W）100×（D）78×（L）183 | |||
|
Weight |
320g |
350g | |||
